Servodrive SINEE EA300E

Descriere

Drive for brushless servomotor

Model: SINEE EA300E-8R5-3B
Nominal motor power: 1.8kW
Nominal voltage: 3x 380Vac

Nominal torque: 11.5Nm

RS232 communication interface:

          Status display, user parameter setting, monitoring display, alarm tracking display, JOG operation and automatic

          tuning operation, speed, torque instruction signal

Feedback: 17bit serial incremental encoder, 23bit serial absolute encoder

EtherCAT communication 100Base-TX full duplex

EtherCAT frame length: 44 - 1,498 bytes

Distributed clock: 64 digits

8 digital inputs

4 digital outputs

Support services: CoE(PDO, SDO)

Instruction synchronization cycle: 1ms or its integral multiple

Support running mode CIA402: Profile Position; Profile Velocity; Profile Torque, Interpolation Position,

                                 Cyclic Synchronous Position, Cyclic Synchronous Velocity, Cyclic Synchronous Torque, Homing

Speed Torque control accuracy: ±3% (current repetition accuracy)

Position control mode:

         Feedforward compensation: 0~100% (set resolution 1%)

         Positioning completion width: 1 - 655,335 instruction units (set resolution to 1 instruction unit)

         Min setting time 5ms (no load, from rated speed to positioning completion)

Warranty: 1 year
